Robust daytime UV-Visible camera DayCor Superb for precise corona and partial-discharge detection
The DayCor Superb is a solar-blind UV-Visible corona camera that detects weak UV emissions (as low as 1 pC at 10 m) even in full daylight. It captures corona or arcing events through UV, visible, or combined imaging and supports both video and still recording.
| Feature | Specification |
|---|---|
| Minimum Discharge Detection | ~1 pC at 10 m |
| UV Sensitivity | ~1.5 × 10⁻¹⁸ W/cm² |
| Spectral Range (UV) | 240–280 nm |
| Image Modes | UV-only, Visible-only, UV+Visible combined |
| Zoom | Rapid optical zoom (visible) + digital UV zoom |
| Focus | Auto & manual focus for UV and visible channels |
| Display | 5″ transflective LCD (OD) or 6.5″ bright LCD (XD) |
| Recording & Storage | Video, audio, and still images on CompactFlash card |
| Build / Use Cases | Rugged, handheld/tripod use, suitable for harsh HV/MV environments |
| Recommended Working Range | Close-up to ~100 m |
