Premium handheld solar-blind UV camera for detecting corona discharges on power systems
The Luminar HD is a high-definition solar-blind UV corona camera designed to detect corona and partial discharge on high-voltage equipment. It delivers strong UV sensitivity, HD video capture, UV-visible overlay, and reliable day-night inspection performance.
| Feature | Specification |
|---|---|
| Spectral Range (UV) | 240–280 nm |
| Minimum Discharge Detection | ~1 pC at 15 m |
| RIV Sensitivity | ~3.6 dBµV @ 1 MHz @ 10 m |
| UV Sensitivity | ~2.2 × 10⁻¹⁸ W/cm² |
| Field of View | 5° × 3.75° and 10° × 7.5° (interchangeable) |
| Zoom | 2× optical UV, continuous visible + digital zoom |
| Focus | Auto or manual for UV and visible channels |
| Display | 5″ sunlight-readable TFT LCD (800×480) |
| Modes | UV-only, Visible-only, UV + Visible overlay |
| Video & Image Capture | HD video (720p), still images, onboard storage, metadata support |
| Connectivity | Wi-Fi, Ethernet, Bluetooth, external video output |
| Weight | ~2.2 kg |
| Protection Rating | IP54 |
| Operating Use | Suitable for indoor/outdoor daylight inspection |
